3-Roller Plate Bending Machine 20-300
CHARACTERISTICS & SPECIFICATIONS
| NUMBER OF ROLLERS | : | 3-roller |
| OPERATION | : | Hydraulic |
| SHEET THICKNESS | : | Min.: 6 mm (0.2 in) | Max.: 22 mm (0.9 in) |
| OTHER CHARACTERISTICS | : | Conical bending capability |
DESCRIPTION
- Very suitable for light and medium plates, aluminium or stainless steel bending
- Ferrules in full circle or varying radiuses can be done easily
- Lateral rolls move with hydraulic pistons in orbital way
- Overload protection
- 3 rolls powered by single planetary gearbox and gear system
- Hydraulic Drop-End for easy removal of finished ferrule
- Easy operation with mobile control panel
- Two digital readouts for easy roll positioning of bottom rolls
- Welded steel frames
- SAE 1050 (CK 45-50) forged or hot rolled, induction hardened and polished steel rolls
- Conical bending device with ball bearing
- Hydraulic balancing system for parallel movement of the rolls
- Extended roll shafts for profile and pipe bending operation
OPTIONAL EQUIPMENTS
- Overhead crane for large diameters
- Hydraulic lateral side supports for large diameters
- Ground rolls for special jobs
- Profile bending rolls set
- Infinitely variable speed adjustment
- Electronic balancing system for parallel movement of the rolls
